AILVLVNG HDMI Displayport KVM Switch

Connection Steps

1. Connect the 12V/1A power adapter to ensure stable operation.
2. Connect DP A + HDMI B and USB-A from each PC to PC 1 IN / PC 2 IN ports.
3. Connect OUT A/B to monitors (OUT A = DP A, OUT B = HDMI B).
4. Plug mouse, keyboard, and other devices into front USB ports. Supports 2 PCs sharing 2 monitors and 4 USB 3.0 ports.
   KVM Switch 2 Monitors
   Allows two PCs with DP and HDMI to share dual monitors, keyboard, and mouse in Extended or Copy mode. Both DP A and HDMI B must connect to the same PC. Not compatible with signal converters or Mac devices.
   Ultra HD Visual Effects
   Supports 4K@60Hz resolution for vivid visuals. Use DP 1.2 and HDMI 2.0 cables under 3.3ft for optimal stability and to avoid screen flicker.
   Support 4 USB Peripherals
   Equipped with 4 USB 3.0 ports to share mouse, keyboard, printer, and more. Backwards compatible with USB 2.0/1.1. Ensure correct USB input connection for device recognition.
   2 Ways to Switch
   Switch signal sources via button on unit or included desktop controller. LED indicator shows active PC. Supports Windows, Mac OS, Linux, Unix. Hotkey switching not supported.
   12V DC Power Adapter
   Ensure each PC supports dual display. Includes 12V power adapter. Comes with 12-month after-sales service via Amazon support.
